Standard equipment and parameters:

WORKING PARAMETERS

• Bucket capacity – 0.67 m³
• Bucket width – 2040 mm
• Bucket type – reinforced, with screw teeth
• Maximum lifting capacity – 2000 kg

LIFT AND DUMPING PARAMETERS

(specific lifting/dumping heights are not indicated on the manufacturer’s page)

CHASSIS AND MANEUVERABILITY

Steering system – articulated frame with hydraulic steering

Minimum turning radius – 5460 mm

The floating articulated design ensures stable wheel contact with the surface, improved traction and frame protection when working on uneven surfaces.

TRANSMISSION AND DRIVE

• Drive system – hydraulic torque converter
• Gearbox type – fixed axle Power Shift
• Shift control oil pressure – 1.2–1.5 MPa
• Nominal input speed – 2500 rpm

Planetary drive provides high torque to the wheels and efficient power transmission.

BRAKE SYSTEM

Service brakes – hydraulic, on all four wheels

Parking brake – manual

WHEELS

Tires – 16/70-20

SAFETY, COMFORT AND CONSTRUCTION

The ER420T is equipped with a TÜV Rheinland CE certificate, a new generation ROPS & FOPS cabin with a maintenance hatch, improved visibility and a vibration-damped work area. An ergonomic workplace, adjustable steering column and comfortable seat allow you to work for long periods without excessive fatigue.

A newly designed engine hood improves cooling and reduces noise levels, while a cast iron rear counterweight significantly improves stability during lifting.
