Standard equipment and parameters:

WORKING PARAMETERS

• Bucket capacity – 0.38 m³
• Bucket width – 1.5 m
• Maximum traction force – 20 kN
• Maximum breakout force – 22 kN
• Maximum gradeability – 20°

LIFT AND DUMPING PARAMETERS

• Maximum dumping height – 2100–2120 mm
• Maximum dumping reach – 735–800 mm
• Lifting distance – 1360 mm
• Boom lifting time – 3 s
• Full cycle time – 7.4 s

CHASSIS AND DIMENSIONS

• Wheelbase – 2170 mm
• Track width – 1200 mm
• Minimum ground clearance – 260 mm

TRANSMISSION AND DRIVE

• Gearbox type – Power shift, permanently engaged spur gear
• Gear shifting – mechanical
• Drive – all-wheel drive (4WD)

The planetary axle increases torque to the wheels, improving traction and digging capacity.

HYDRAULIC SYSTEM

• System working pressure – 18 MPa
• Automatic leveling function – yes
• Fuel tank capacity – 55 l

BRAKE SYSTEM

• Service brakes – mechanical, drum type
• Parking brake – manual, disc type

WHEELS

• Tire size – 31×15.5–15
• Front tire pressure – 310 kPa
• Rear tire pressure – 310 kPa

STRUCTURE, SAFETY AND COMFORT

The ER408T is equipped with a newly designed ROPS & FOPS cab with a maintenance hatch, improved visibility and a vibration-damped work area. An adjustable steering column, ergonomic joystick and comfortable seat ensure comfortable work under long-term load conditions.

A newly designed engine hood reduces noise levels and improves cooling, while a cast iron rear bumper improves balance and stability.
